Hollow Section Rectangular Pipe JIS/KS 2x2 180x180mm Welded ERW Carbon square Steel Pipes Tubing

Name	Square and rectangular steel pipe
Outside Diameter	2020-200200 mm
Wall Thickness	1.5-30 mm
Length	1-12 m

product details

Product Tags

Description

Square tube is a hollow square cross-section light thin-walled steel tube, also known as steel cold-bent profile. It is a square cross-section steel made of Q235 hot-rolled or cold-rolled strip or coil as the base material, which is formed by cold bending and then high-frequency welding. In addition to the thickening of the wall thickness, the corner size and edge straightness of the hot-rolled extra-thick-walled square tube reach or even exceed the level of the resistance-welded cold-formed square tube. It has good comprehensive mechanical properties, good weldability, cold and hot processing performance and corrosion resistance, and good low-temperature toughness.

Square tube uses

Square tubes are used in projects such as construction, machinery manufacturing, steel construction, shipbuilding, solar power generation brackets, steel structure engineering, power engineering, power plants, agricultural and chemical machinery, glass curtain walls, automobile chassis, airports, boiler construction, highway railings, house construction, pressure vessels, oil storage tanks, bridges, power station equipment, lifting and transportation machinery and other high-load welded structural parts.

Product Parameters

Product Name	High Quality Galvanized Square And Rectangular Steel Pipes And Tubes
Material	Q195 Q235 Q345
Wall Thickness	1MM-12MM
Size	10MMX10MM-600MM-600MM
Length	Length:Single random length/Double random length5m-14m,5.8m,6m,10m-12m,12m or as customer's actual reques
Standard	ASTM A53,BS1387-1985,GB/T3091-2001,GB/T13793-92, GB/T6728- 2002,API 5L
Packing	Bundle, or with all kinds of colors PVC or as your requirements
Pipe Ends	Plain end/Beveled,protected by plastic caps on both ends, cut quare,grooved,threaded and coupling,etc.
Product Application	1. Fence, greenhouse, door pipe,greenhouse 2. Low pressure liquid, water, gas, oil, line pipe 3. For both indoor and outdoor the building construction 4. Widely used in scaffolding construction which is much cheaper and convenient
