Product Description
Uses of stainless steel angle steel
Stainless steel angle steel can be used to form various load-bearing components according to different structural needs, and can also be used as connectors between components. It is widely used in various building structures and engineering structures, such as beams, bridges, transmission towers, lifting and transportation machinery, ships, industrial furnaces, reaction towers, container racks, and warehouse shelves.
Stainless steel angle steel is a carbon structural steel for construction. It is a simple cross-section steel material, mainly used for metal components and factory frames. It requires good weldability, plastic deformation performance and certain mechanical strength during use. The raw material billet for producing stainless steel angle steel is low-carbon square billet, and the finished stainless steel angle steel is delivered in hot-rolled, normalized or hot-rolled state.
Traditional universal angle steel:
The size is relatively free, but the hole spacing needs to be rigorously calculated. Even professional craftsmen may still have errors, and the locking process is cumbersome. It is suitable for assembly with power tools, so its market acceptance is low, but it still has its loyal fans.
Screw-free angle steel:
Compared with universal angle steel, its size is relatively fixed, but its assembly is easier, which can save about three times the assembly time. It is also relatively stable, with more diverse color options and in line with modern aesthetics, so it has gradually become the mainstream in the market.
Product Parameters
equal angle steel | |||||
(mm) | (kg/m) | (mm) | (kg/m) | (mm) | (kg/m) |
25*3 | 1.124 | 75*7 | 7.976 | 110*14 | 22.809 |
25*4 | 1.459 | 75*8 | 9.03 | 125*8 | 15.504 |
30*3 | 1.373 | 75*10 | 11.089 | 125*10 | 19.133 |
30*4 | 1.786 | 80*6 | 7.376 | 125*12 | 22.696 |
40*3 | 1.852 | 80*7 | 8.525 | 125*14 | 26.193 |
40*4 | 2.422 | 80*8 | 9.658 | 140*10 | 21.488 |
40*5 | 2.976 | 80*10 | 11.874 | 140*12 | 25.522 |
50*4 | 3.059 | 90*6 | 8.35 | 140*14 | 29.49 |
50*5 | 3.77 | 90*7 | 9.658 | 140*16 | 35.393 |
50*6 | 4.465 | 90*8 | 10.946 | 160*10 | 24.729 |
60*5 | 4.52 | 90*10 | 13.476 | 160*12 | 29.391 |
60*6 | 5.42 | 90*12 | 15.94 | 160*14 | 33.987 |
63*5 | 4.822 | 100*6 | 9.366 | 160*16 | 38.518 |
63*6 | 5.721 | 100*7 | 10.83 | 180*12 | 33.159 |
63*8 | 7.469 | 100*8 | 12.276 | 180*14 | 38.518 |
63*10 | 9.151 | 100*10 | 15.12 | 180*16 | 43.542 |
70*5 | 5.397 | 100*12 | 20.611 | 180*18 | 48.634 |
70*6 | 6.406 | 100*16 | 23.257 | 200*14 | 42.894 |
70*7 | 7.398 | 110*7 | 11.928 | 200*16 | 48.68 |
70*8 | 8.373 | 110*8 | 13.532 | 200*18 | 54.401 |
75*5 | 5.818 | 110*10 | 16.69 | 200*20 | 60.056 |
75*6 | 6.905 | 110*12 | 19.782 |
Unequal angle steel | |||||
(mm) | (kg/m) | (mm) | (kg/m) | (mm) | (kg/m) |
25*16*3 | 0.912 | 75*50*8 | 7.431 | 125*80*7 | 11.066 |
32*20*3 | 1.171 | 75*50*10 | 9.098 | 125*80*8 | 12.551 |
32*20*4 | 1.522 | 80*50*5 | 5.005 | 125*80*10 | 15.474 |
40*25*3 | 1.484 | 80*50*6 | 5.935 | 125*80*12 | 18.33 |
40*25*4 | 1.936 | 80*50*7 | 6.848 | 140*90*8 | 14.1 |
45*28*3 | 1.687 | 80*50*8 | 7.745 | 140*90*10 | 17.475 |
45*28*4 | 2.203 | 90*56*5 | 5.661 | 140*90*12 | 20.724 |
50*32*3 | 1.908 | 90*56*6 | 6.717 | 140*90*14 | 23.908 |
50*32*4 | 2.494 | 90*56*8 | 8.779 | 160*100*10 | 19.872 |
56*36*3 | 2.153 | 100*63*7 | 8.722 | 160*100*14 | 27.274 |
56*36*4 | 2.818 | 100*63*8 | 9.878 | 160*100*16 | 30.853 |
56*39*5 | 3.466 | 100*63*10 | 12.142 | 180*110*10 | 22.273 |
63*40*4 | 3.185 | 100*80*6 | 8.35 | 180*110*12 | 26.464 |
63*40*5 | 3.92 | 100*80*7 | 9.656 | 180*110*14 | 30.589 |
63*40*6 | 4.638 | 100*80*8 | 10.946 | 180*110*16 | 34.649 |
70*45*5 | 4.403 | 100*80*10 | 13.476 | 200*125*12 | 29.761 |
70*45*6 | 5.218 | 110*70*6 | 8.35 | 200*125*14 | 34.436 |
70*45*7 | 6.011 | 110*70*7 | 9.656 | 200*125*16 | 39.045 |
75*50*5 | 4.808 | 110*70*8 | 10.946 | 200*125*18 | 43.588 |
75*50*6 | 5.699 | 110*70*10 | 13.476 |
Production Flow Chart

Project Case



Pack And Ship

Certificate






Customer Praise



Plant And Equipment




FAQ
Q: What the main products you can supply?
A: We are a professional and famous factory in China. The main products of our company include Stainless Steel Sheet/Coils/Tubes/Bars/Corrugated Sheets, Carbon Steel Sheets/Coils/Tubes, Galvanized Sheets/Coils/Tubes/Bars/Corrugated Sheets, PPGI/PPGL Sheets, PPGI/PPGL Coils, PPGI/PPGL Corrugated Sheets, Ductile Iron Pipe, Copper, Aluminum, etc.
Q: What is your payment terms?
A:Commonly two payment term for new customers
1) 30%T/T as deposit, 70% balance against B/L copy.
2) 100% Irrevocable L/C at sight.
If you need other terms, please feel free to contact us. We will try our best.
Q: How about the samples? Is it free or extra fees?
A: Usually, we would like to supply the samples before order. If the samples are in stock, it will be free. If the samples need to be produced, we will charge some reasonable cost. But this amount will be deducted from your first order invoice.
Q: How long is your delivery time?
A: Our daily inventory is more than 8000 tons, so common products size orders just need 5 days from stocks. If there are special size order, it will cost 7-15 days.
