Wire rods
Low Price 1mm-10mm Galvanized Steel Wire Used for Hangers Rope High Carbon Metal Wire Rod
Product Description
By material
According to the material, it is divided into carbon steel wire rope, alloy steel wire rope and stainless steel wire rope.
Carbon steel wire rope: refers to the steel wire rope made of ordinary carbon steel with a carbon content between 0.1% and 0.9%, which is the most commonly used type
Low cost, high strength, but poor corrosion resistance, easy to rust. Carbon steel wire rope is mainly used for general purpose and special purpose, etc.
Alloy steel wire rope: refers to the steel wire rope made of alloy steel containing a certain proportion of alloying elements, such as manganese, silicon, chromium, nickel, etc., which is characterized by higher strength, better toughness, better wear resistance, better heat resistance, but higher cost. Alloy steel wire rope is mainly used for hoisting machinery, mining equipment and petroleum equipment under special working conditions such as high temperature, high speed and high pressure.
Stainless steel wire rope: refers to the steel wire rope made of stainless steel containing a certain proportion of chromium, nickel and other stainless elements, which is characterized by excellent corrosion resistance, good high temperature resistance, and beautiful appearance, but low strength and high cost. Stainless steel wire rope is mainly used in chemical, food, pharmaceutical and other industries, as well as marine environment and high temperature environment.
Product Parameters
| Material | Q195/Sae1006/Sae1008/Sea1020 |
| Tolerance | ±5% |
| Standard | ASTM/GB |
| Processing services | Cutting/Bending |
| Shipping date | 15-21days |
| Price terms | FOB/CFR/CIF/EXW/ETC |
| Application | Construction |
| Package | Standard Sea-worthy Packing |
| Galvanized steel wire | |||||
| Diameter （mm） | Tolerance (mm) | Tensile Strength No Less Than (MPA) | Torsion Test No less Than (times) | Bend Times No Less Than (times) | Zinc Coating Mass No Less Than (g/m2) |
| 0.45 | +/-0.01 | 1770 | 28 | 5 | 5 |
| 0.5 | +/-0.01 | 1770 | 28 | 5 | 5 |
| 0.6 | +/-0.01 | 1770 | 28 | 9 | 5 |
| 0.7 | +/-0.01 | 1670 | 28 | 7 | 10 |
| 0.8 | +/-0.01 | 1670 | 28 | 13 | 10 |
| 0.9 | +/-0.02 | 1570 | 28 | 11 | 15 |
| 1 | +/-0.02 | 1470 | 27 | 9 | 20 |
| 1.2 | +/-0.02 | 1470 | 27 | 15 | 20 |
| 1.3 | +/-0.02 | 1370 | 27 | 13 | 20 |
| 1.4 | +/-0.02 | 1370 | 27 | 11 | 20 |
| 1.6 | +/-0.03 | 1370 | 27 | 13 | 20 |
| 1.8 | +/-0.03 | 1370 | 27 | 11 | 30 |
| 2 | +/-0.03 | 1270 | 25 | 10 | 30 |
| 2.4 | +/-0.03 | 1270 | 25 | 11 | 30 |
| 2.6 | +/-0.03 | 1270 | 25 | 10 | 35 |
| 2.77 | +/-0.03 | 1270 | 25 | 9 | 35 |
Production Flow Chart
Project Case
Pack And Ship
Certificate
Customer Praise
Plant And Equipment
FAQ
1: What is your terms of payment?
A: 30% T/T as the upfront deposit, 70% before delivery. We will show you the photos of products and package before you pay the balance.
Q2: What is the terms of delivery?
A: EXW, FOB, CIF, CFR, DDU
Q3: What is the terms of packing?
A: generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers’ requirement.
Q4: What is your delivery time?
A: For stocks, we could transport the goods to loading port within 7 days after we received your deposit. For production period, it usually takes about 15 days-30 days after receiving the deposit.
Q5: Could you produce according to the samples?
A : Yes, we could customer-made by your samples or technique drawings, we could build the mold and fixtures.
Q6: Could you provide the samples?
A: yes, we could provide the free samples on conditions it is available in stocks, however, the transportation fee is borne by buyer.
Q7: How could you guarantee your products?
A: Each piece of products is manufactured by certified workshops, inspected by SORUN piece by piece according to national QA/QC standard. We also could issue the warranty to customer to guarantee the quality.
